AM2500 SELF-LOADING CONCRETE MIXER
KEY SPECIFICATIONS
2.5m³ Concrete Output
78kW Engine Power
6500kg Operating Weight
PRODUCT HIGHLIGHTS
01 EFFICIENT AUTOMATIC BATCHING High-capacity self-loading bucket and precise automatic water metering ensure fast, high-quality concrete mixing.
02 4WD & ARTICULATED CHASSIS Four-wheel drive transmission paired with an articulated steering system offers high maneuverability and stability across rough terrain.
03 270° ROTATING DRUM Hydraulic drum rotation up to 270° allows seamless concrete discharge in all directions.
TECHNICAL SPECIFICATIONS – AM2500 SELF-LOADING CONCRETE MIXER
1. General Specifications
| Specification Item | Value / Standard |
| Engine Model | Yuchai YCD4J22T-78 / Yunnei Turbocharged |
| Engine Power | 78 kW / 2400 rpm |
| Concrete Output Capacity | 2.5 m³ per batch |
| Operating Weight | 6,500 kg |
| Number of Cylinders | 4 |
2. Dimensions
| Specification Item | Value |
| Overall Length | 6,500 mm |
| Overall Width | 2,400 mm |
| Overall Height | 3,050 mm |
| Wheelbase | 2,250 mm |
| Track Width | 1,700 mm |
| Min. Ground Clearance | 310 mm |
| Bucket Capacity | 0.5 m³ |
3. Working & Mixing Performance
| Specification Item | Value |
| Drum Rotation Speed | 0 – 20 rpm |
| Discharge Angle | 270° |
| Max. Travel Speed | 28 km/h |
| Gradeability | 30% (16.7°) |
| Water Supply System | Self-priming hydraulic pump |
| Water Tank Capacity | 550 L |
4. Transmission & Steering
| Specification Item | Value / Description |
| Drive System | 4WD Hydrostatic / Mechanical |
| Shift Gears | 4 Forward / 4 Reverse |
| Braking System | Air Brake |
| Tire Size | 16/70-20 |
| Steering Type | Articulated Hydraulic Steering |
5. Capacities
| Tank / System | Capacity |
| Fuel Tank | 95 L |
| Hydraulic Oil Tank | 95 L |
| Engine Oil | 10 L |
| Water Tank | 550 L |
